Labeler SXT-D-2
The bottle inverter machine for cap sterilization employs advanced drive chain that ensures high stability and reliability, no damage to the bottle, and continuously adjustable speed.
| Shell Material of Machine | 304# Stainless Steel |
| Machine & Conveying Belt Motor | Taiwan |
| Machine Frequency Converter | Taiwan |
| Conveying Belt Chain | Japan |
| Pressure Control | GermanySICK |
| Bottle Diameter | 30-95 |
| Label Size | 50-280*40-150 |
| Production Speed | 80-100 bottles/min |
Labeler SXT-D-1
Full-automatic high speed labeler for round bottles
| Description | Available to work independently or connect with a production line |
| Applicable Bottle Shape | Round, Square and Cone Plastic Bottles and Glass Bottles |
| Alarm Function | Alarm for no chromatapes, broken labels, and insufficient labels |
| Diameter of Bottle Shape | φ10-120mm(H) φ20-300mm |
| Labeling Scope | (H) 15-150mm(L) 25-300mm |
| Inner Diameter of Scroll | φ76mm |
| Outer Diameter of Scroll | φ300mm(Maximum) |
| Labeling Speed | 200-400 bottles/min |
| Accuracy Error | ±0.5 (Depended by Bottle Circularity and Verticality) |
| Voltage | 220V50/60HZ 1.2KW |
| Weight | 220KG |
| Bottle Supply Turnplate | 60KG |
| External Dimensions | 1,500*800*1,300mm |
