Perfectly combining the reliability of gear pump and the wear resistance of diaphragm pump, this inkjet printer comes with unrivalled stability and cost efficiency. The continuous inkjet printer is designed with a more user-friendly operation system which integrates multiple cutting edge technologies in the world. This completely presents the excellence on stability and flexibility of this continuous inkjet coding printer.
Technical Parameters of the Inkjet Printer| Inkjet printing rows | 1, 2 rows (7 x 5, 7 x 7 dot matrix) |
| Dot matrix font | 7 x 5, 7 x 7, 10 x 7, 12 x 12, 16 x 10, 16 x 16 |
| Printing direction | Positive sequence, inverted order, reverse and overturn; regulated at will |
| Language options | The inkjet coder can print using a combination of Chinese, English, Figure, etc. |
| Printing speed | 7 x 5 single-line: 1076 words/sec; 7 x 5 dual-line: 476words/sec/line 10 x 7: 359 words/sec; 12 x 12: 156 words/sec; 16 x 16: 116 words/sec |
| Printing range | 2mm -12mm |
| Available to reach 9 times bold ratio Automatic displaying product quantity, batch number and code |
|
| Net weight | 25kg |
| Size (H x W x T) | 580mm x 420mm x 263mm |
| Rated current | 2A |
| Voltage | 220V( ±15%) |
| Working temperature | 5-45 ℃ |
| Humidness | 30%-95%, no condensed water |
| Distance between paint head and machine | ≤3m |
Model: PMJ
Capacity: 24000bph
Brand: France
Quantity: 1 set
Parameters:
Operation interface
Display type: 1/4VGA Backlight super developer
Distinguishability: 240x320VGA
Input keyboard: In order of QWERTY normal touch keyboard
Character types: Digital panel, letters, the direction key, words stock
Control mode: RUN (AUTO), DEMO(manual), STOP(standby)
Intensity of the laser: A touch function keys
Graphical display: built-in colour display screen
Dimension (HxWxL): 159mm x 240mm x 44mm (6.25"x9.45"x1.75")
Printer
Printing lines: not restricted within the scope of the printing
Number of characters printed: not restricted within the scope of the printing
Print range (HxW): 50mm x 80mm (2.0"x3.2")
Character format: Mixed multi-select, Maximum 255 x255 lattice point
Character type: Letters, Chinese characters, icons, symbols, etc
Character size: 0.5mm-51mm (0.02"-2.0")
Image azimuth: 0~360 degree
Printing azimuth: 0~90 degree adjustable
Laser type: 10W, air cooling, electrode CO2 laser
Protection class: IP20C, standard
Dustproof: Yes, selectable
Working humidity: 5°C-40°C (41°F-105°F)
Network interface: RS232, Standard/Ethernet network selectable
Supply voltage: 100-120/200-240V/50-60HZ, 225W
Dimension(HxWxL): 114mm x 165mm x 597mm (4.5"x6.5"x23.5")
Weight: 10kg
Printing speed: 400m/sec, high print 90m/min
